Acura TLX II (2020-2024) automatic lighting sensor control unit Wiring diagrams
This page contains all the electrical diagrams for the component. automatic lighting sensor control unit, in which he is found in the car Acura TLX II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
automatic lighting sensor control unit wiring diagram (1 of 2)
AUTOMATIC LIGHTING SENSOR CONTROL UNIT
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S FOOTWELL LIGHT
DRIVER'S INSTRUMENT PANEL AMBIENT LIGHT
FRONT PASSENGER'S DOOR AMBIENT LIGHT
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FUSE 17
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
JUNCTION BOX B
LIGHT (LEDS)
LT GRN WIRE
MAP LIGHTS
MASTER LIGHTING CONTROL UNIT (RIGHT SIDE OF DASH)
OFF
PASSENGER'S INSTRUMENT PANEL AMBIENT LIGHT
PNK WIRE
REAR AMBIENT LIGHT
REAR INDIVIDUAL MAP LIGHT
RED WIRE
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR SWITCH
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
YEL WIRE
Go to component -> Courtesy lamps circuit, w/ master lighting control (3 of 3) -> AUTOMATIC LIGHTING SENSOR CONTROL UNIT
automatic lighting sensor control unit wiring diagram (2 of 2)
AUTOMATIC LIGHTING SENSOR CONTROL UNIT
AUTOMATIC LIGHTING/ RAIN SENSOR
BASE
BLK WIRE
BRN WIRE
DRIVER'S FOOTWELL LIGHT
DRIVER'S INSTRUMENT PANEL AMBIENT LIGHT
EXCEPT BASE
FRONT PASSENGER'S DOOR AMBIENT LIGHT
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FUSE 17
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
JUNCTION BOX B
LIGHT (LEDS)
LT GRN WIRE
MAP LIGHTS
OFF
PASSENGER'S INSTRUMENT PANEL AMBIENT LIGHT
PPL
REAR AMBIENT LIGHT
REAR INDIVIDUAL MAP LIGHT
RED WIRE
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR SWITCH
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
YEL WIRE
Go to component -> Courtesy lamps circuit, w/o master lighting control (3 of 3) -> AUTOMATIC LIGHTING SENSOR CONTROL UNIT
