Acura TLX II (2020-2024) automatic dimming inside mirror/homelink unit Wiring diagrams
This page contains all the electrical diagrams for the component. automatic dimming inside mirror/homelink unit, in which he is found in the car Acura TLX II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram automatic dimming inside mirror/homelink unit (1 of 2)
AUTOMATIC DIMMING INSIDE MIRROR/HOMELINK UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONSOLE BOX LIGHT
DIMMER CIRCUIT
DOOR SWITCH IND
FRONT AMBIENT LIGHT
GAUGE CONTROL MODULE
GRY WIRE
INTERIOR LIGHT SWITCH (DOOR)
INTERIOR LIGHT SWITCH (OFF)
INTERIOR LIGHT SWITCH (ON)
LEFT FRONT INDIVIDUAL MAP LIGHT
LEFT FRONT INDIVIDUAL MAP LIGHT SWITCH
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR SWITCH
LIGHT (LED)
LT GRN WIRE
MICRO CONTROLLER
PNK WIRE
PPL
RED WIRE
RIGHT FRONT INDIVIDUAL MAP LIGHT
RIGHT FRONT INDIVIDUAL MAP LIGHT SWITCH
RIGHT REAR DOOR INNER HANDLE LIGHT
ROOF MODULE (ABOVE REAR VIEW MIRROR)
TAN WIRE
TRUNK LIGHT
YEL WIRE
Go to component -> Courtesy lamps circuit, w/ master lighting control (2 of 3) -> AUTOMATIC DIMMING INSIDE MIRROR/HOMELINK UNIT
Wiring diagram automatic dimming inside mirror/homelink unit (2 of 2)
AUTOMATIC DIMMING INSIDE MIRROR/HOMELINK UNIT
BASE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONSOLE BOX LIGHT
DIMMER CIRCUIT
DOOR SWITCH IND
EXCEPT BASE
FRONT AMBIENT LIGHT
GAUGE CONTROL MODULE
GRY WIRE
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT SWITCH (DOOR)
INTERIOR LIGHT SWITCH (OFF)
INTERIOR LIGHT SWITCH (ON)
LEFT FRONT INDIVIDUAL MAP LIGHT
LEFT FRONT INDIVIDUAL MAP LIGHT SWITCH
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR SWITCH
LIGHT (LEDS)
LT GRN WIRE
MICRO CONTROLLER
PNK WIRE
PPL
RED WIRE
RIGHT FRONT INDIVIDUAL MAP LIGHT
RIGHT FRONT INDIVIDUAL MAP LIGHT SWITCH
RIGHT REAR DOOR INNER HANDLE LIGHT
ROOF MODULE (ABOVE REAR VIEW MIRROR)
TAN WIRE
TRUNK LIGHT
YEL WIRE
Go to component -> Courtesy lamps circuit, w/o master lighting control (2 of 3) -> AUTOMATIC DIMMING INSIDE MIRROR/HOMELINK UNIT
