Acura TLX II (2020-2024) acc combination switch Wiring diagram
This page shows the only wiring diagram for the component.acc combination switch, which is found in the car Acura TLX II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acc combination switch (11 of 11)
ACC COMBINATION SWITCH
AUDIO REMOTE- HFL SWITCH
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
CABLE REEL
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER
FUSE 17
FUSE 2-6
FUSE 4-2
FUSE 48
FUSE/RELAY HOLDER C
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HOT AT ALL TIMES
JUNCTION BOX B
LT GRN WIRE
MCU
PNK WIRE
POWER DISTRIBUTION MODULE
POWER DISTRIBUTION SYSTEM
RED WIRE
REGULATOR
SMART FET
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> ACC COMBINATION SWITCH
