Courtesy lamps circuit for Acura TLX I facelift (2017-2020)

AUTOMATIC LIGHTING SENSOR CONTROL UNIT AUTOMATIC LIGHTING/ RAIN SENSOR BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR DOOR DRIVER'S VANITY MIRROR LIGHT FUSE 5 GRN WIRE GRY WIRE ILLUMINATION CIRCUIT INTERIOR LIGHTS CUT RELAY JUNCTION BOX 1 (LEFT SIDE OF DASH) LT BLU WIRE LT GRN WIRE MICU OFF OFF ON ON OFF OPTION CONNECTOR (FOR RIGHT LED) PNK WIRE REAR INDIVIDUAL MAP LIGHT RED WIRE RELAY ENERGIZED ROOF CONSOLE MODULE (ABOVE REAR VIEW MIRROR) TAN WIRE TRUNK LID LATCH TRUNK LID RELEASE ACTUATOR TRUNK LIGHT UNDER-DASH FUSE/RELAY BOX UNDER-DASH RELAY HOLDER C W/ AUTOMATIC WIPER W/O AUTOMATIC WIPER WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR COURTESY LIGHT DRIVER'S DOOR SWITCH FRONT PASSENGER'S DOOR COURTESY LIGHT FRONT PASSENGER'S DOOR SWITCH FUSE 19 FUSE 9 GRN WIRE HOT AT ALL TIMES LEFT REAR DOOR SWITCH LT BLU WIRE LT GRN WIRE OFF OPTION CONNECTOR (FOR LEFT LED) PASSENGER'S VANITY MIRROR LIGHT RIGHT REAR DOOR SWITCH UNDER-HOOD FUSE/RELAY BOX W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM YEL WIRE
