Headlights circuit for Acura TLX I facelift (2017-2020)

AUXILIARY UNDER-HOOD FUSE/RELAY BOX BLK WIRE BLU WIRE BRN WIRE FOG LIGHT RELAY (IF EQUIPPED) FUSE 10 FUSE 12 FUSE 2-4 FUSE 29 GRN WIRE GRY WIRE HEADLIGHT HIGH BEAM RELAY HEADLIGHT LOW BEAM RELAY HOT AT ALL TIMES LEFT FOG LIGHT LEFT HEADLIGHT LT GRN WIRE PPL RED WIRE RELAY HOLDER A RIGHT FOG LIGHT RIGHT HEADLIGHT TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

32 BIT MICROCOMPUTER+FLASH ROM AUTO AUTOMATIC LIGHTING SENSOR CONTROL UNIT AUTOMATIC LIGHTING/ RAIN SENSOR AUXILIARY UNDER-DASH FUSE BOX B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM CRUISE LIGHT DC-DC CONVERTER DIMMING CIRCUIT ELECTRIC PARKING BRAKE SWITCH FRONT FOG LIGHT IND FRONT FOG LIGHT SWITCH FUSE 29 FUSE 39 FUSE 8 FUSE FD GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEAD HIGH BEAM IND HOT AT ALL TIMES JUNCTION BOX 1 (LEFT SIDE OF DASH) JUNCTION BOX 2 (+) LIGHTS ON IND LT BLU WIRE LT GRN WIRE MICU MULTI INFORMATION DISPLAY (TFT) OFF PARK PASS PNK WIRE PPL RED WIRE SUNLIGHT SENSOR W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM WARNING DRIVER CIRCUIT WHT WIRE YEL WIRE
