Computer data lines circuit for Acura TLX I facelift (2017-2020)

2.4L 3.5L BLK WIRE BLU WIRE CABLE REEL (TOP OF STEERING COLUMN) CAN GATEWAY DATA LINK CONNECTOR (DLC) ELECTRIC PARKING BRAKE CONTROL UNIT FUSE 29 FUSE 7 GRN WIRE GRY WIRE HOT AT ALL TIMES JUNCTION BOX 1 (-) LT BLU WIRE MICU MULTIPURPOSE CAMERA UNIT PNK WIRE PPL PRECISION ALL WHEEL STEER CONTROL UNIT RED WIRE RELAY ENERGIZED STEERING ANGLE SENSOR STEERING COMMANDER SWITCH ASSEMBLY TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE

2.4L 3.5L BLK WIRE BLU WIRE ENGINE MOUNT CONTROL UNIT EPS CONTROL UNIT GAUGE CONTROL MODULE GRY WIRE LT BLU WIRE PNK WIRE PPL RED WIRE SBW SHIFTER CONTROL MODULE TAN WIRE TRANSMISSION ASSEMBLY TRANSMISSION CONTROL MODULE VSA MODULATOR CONTROL UNIT W/ AUTO IDLE SYSTEM W/O AUTO IDLE SYSTEM WHT WIRE

2.4L 3.5L ANC/ACTIVE SOUND CONTROL UNIT AUDIO UNIT/AUDIO NAVIGATION UNIT AUTOMATIC LIGHTING/ RAIN SENSOR BLU WIRE GRY WIRE LEFT SIDE BSI RADAR UNIT LT BLU WIRE MULTIVIEW CAMERA UNIT PNK WIRE PPL RED WIRE RIGHT SIDE BSI RADAR UNIT SH-AWD CONTROL UNIT SRS UNIT WHT WIRE WIRELESS CHARGER

2.4L 3.5L BLU WIRE CENTER JUNCTION CLIMATE CONTROL UNIT GRY WIRE HANDS FREE LINK CONTROL UNIT/ TELEMATICS CONTROL UNIT JUNCTION BOX 1 (-) JUNCTION BOX 2 (LEFT SIDE OF DASH) KEYLESS ACCESS/TPMS CONTROL UNIT LT BLU WIRE MICU PARKING, BACKUP SENSOR CONTROL UNIT PNK WIRE POWER SEAT CONTROL UNIT POWER WINDOW MASTER SWITCH PPL RED WIRE UNDER-DASH FUSE/RELAY BOX VENTILATED SEAT CONTROL UNIT/ FRONT SEAT HEATER CONTROL UNIT WHT WIRE
