Fuel door release circuit for Acura TL IV facelift (2011-2014)
Fuel door release circuit
33 35 14 2 32 B-CAN LO B-CAN HI PNK WIRE
B CAN B CAN HI LO
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DRIVER'S MICU
FUEL FILL DOOR OPENER RELAY
FUEL FILL DOOR OPENER SOLENOID (LEFT SIDE OF TRUNK)
FUEL FILL DOOR OPENER SWITCH
FUEL LID ACT
FUEL LID SG
FUSE 16
HOT AT ALL TIMES FUSE 25
HOT IN ON DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
JUNCTION CONNECTOR
LT GRN WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
TRUNK LID OPENER/ FUEL FILL DOOR OPENER SWITCH
YEL WIRE
