Acura TL IV facelift (2011-2014) switch 3 mirror direction switch Wiring diagram
This page shows the only wiring diagram for the component.switch 3 mirror direction switch, which is found in the car Acura TL IV facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch 3 mirror direction switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BUTTON
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
DRIVING POSITION MEMORY SWITCH
DRIVING POSITION MEMORY SWITCH LIGHT
EXCEPT A/T W/ VENTILATED SEATS A/T W/ VENTILATED SEATS
FUSE 12
FUSE 15
FUSE 16
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
LEFT
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK LEFT WIRE
PNK WIRE
POSITION
POSITION 1 INDICATOR
POSITION 2 INDICATOR
POWER MIRROR CONTROL UNIT (IN DRIVER'S DOOR)
POWER MIRROR SWITCH
PPL
PPL UART
RED WIRE
RIGHT
SEAT) POWER SEAT CONTROL UNIT
SET BUTTON
SWITCH 1
SWITCH 2
SWITCH 3 MIRROR DIRECTION SWITCH
UART LVM LMC LHM RMC RHM RSEV RSEH
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VBU
WHT WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> SWITCH 3 MIRROR DIRECTION SWITCH
