Acura TL IV facelift (2011-2014) sil dr Wiring diagrams
This page contains all the electrical diagrams for the component. sil dr, in which he is found in the car Acura TL IV facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sil dr (1 of 2)
B-CAN
B-CAN LO
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCK SWITCH
DOOR LOCK SWITCH CONTROL UNIT
DOOR LOCK SWITCH LOCK LIGHT
DOOR LOCK SWITCH UNLOCK LIGHT
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S DOOR SWITCH (IN DRIVER'S PILLAR BEHIND DOOR)
FRONT PASSENGER'S DOOR LOCK ACTUATOR
FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (IN FRONT PASSENGER'S PILLAR BEHIND DOOR)
FRONT PASSENGER'S POWER WINDOW SWITCH
GRN WIRE
KNOB UN LK
LEFT REAR DOOR SWITCH (IN LEFT REAR PILLAR BEHIND DOOR)
LOCK
LOCK SIL DR
LT BLU WIRE
LT GRN WIRE
MAIN ILLUMINATION
PNK COMPUTER DATA LINES SYSTEM WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
REAR VIEW CAMERA CONNECTOR
RIGHT END OF DASH)
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT REAR DOOR SWITCH (IN RIGHT REAR PILLAR BEHIND DOOR)
SECURITY HOOD SWITCH (INTEGRAL TO ENGINE COMPT
SIL DR
TRUNK LID SPOILER SWITCH
UART
UNLOCK
VMP AS
VMP DR
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Forced entry circuit, with keyless access (2 of 5) -> SIL DR
