Acura TL IV facelift (2011-2014) resume/ accel set/ decel cancel switch switch switch Wiring diagram
This page shows the only wiring diagram for the component.resume/ accel set/ decel cancel switch switch switch, which is found in the car Acura TL IV facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram resume/ accel set/ decel cancel switch switch switch (1 of 1)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL MOUNTING BRACKET)
BRN WIRE
CABLE REEL (A, B: IN STEERING COLUMN) (C: IN STEERING WHEEL)
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
CRUISE CONTROL COMBINATION/SELECT/RESET INFORMATION SWITCH
CRUISE CONTROL IND
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL MAIN SWITCH IND
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
FAST CONTROLLER
FUSE
FUSE FUSE 12
FUSE HORN RELAY OF ENGINE COMPT)
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HORN SWITCH
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
NEXT SWITCH
ORG/ WIRE
RED WIRE
RELAY CIRCUIT BOARD
RESUME/ ACCEL SET/ DECEL CANCEL SWITCH SWITCH SWITCH
RIGHT END OF DASH)
SELECT/ RESET PREVIOUS SWITCH SWITCH
STEERING WHEEL)
TRANSCEIVER AREA NETWORK
TRANSMISSIONS SYSTEM
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> RESUME/ ACCEL SET/ DECEL CANCEL SWITCH SWITCH SWITCH
