Driver"s memory seat circuit for Acura TL IV (2008-2011)

ATP-P BLK WIRE BLK/BLU WIRE BLU WIRE BLU/RED WIRE BRN WIRE DRIVER'S JUNCTION BOX 1 DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH) DRIVER'S POWER SEAT FRONT UP-DOWN MOTOR/POSITION SENSOR (UNDER DRIVER'S SEAT) DRIVER'S POWER SEAT REAR UP-DOWN MOTOR/POSITION SENSOR (UNDER DRIVER'S SEAT) DRIVER'S POWER SEAT RECLINE MOTOR/POSITION SENSOR (IN DRIVER'S SEAT BACK) DRIVER'S POWER SEAT SLIDE MOTOR/POSITION SENSOR (UNDER DRIVER'S SEAT) DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) ENGINE CONTROLS SYSTEM FHM - SLRR - FUSE 12 FUSE 15 FUSE 19 FUSE 21 GND RESE SLSE FHSE RHSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK RHUP RECLINE SW SLFW WIRE PNK WIRE POWER MIRROR CONTROL UNIT (IN DRIVER'S DOOR) POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT) PPL PPL FHM + SL FR + GND PPL UART B-CAN LO B-CAN HI COMPUTER DATA PNK LINES SYSTEM WIRE REC + RHM - REC - PNK WIRE RED WIRE RHDN FHDN FHUP RECLINE SW SLFW RHM + SEG SENSOR SVCC TRANSMISSION RANGE SWITCH (ON TRANSAXLE UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) VBU WHT WIRE YEL WIRE

B-CAN HI B-CAN LO BACK BLK WIRE BLU WIRE BRN WIRE BUTTON CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CONTROL UNIT POWER WINDOW MASTER SWITCH DRIVER'S POWER SEAT ADJUSTMENT SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) DRIVING POSITION MEMORY LIGHT SWITCH DRIVING POSITION MEMORY SWITCH FUSE 12 FUSE 16 FUSE 24 GND GND GND GND GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START LT BLU WIRE LT GRN WIRE MEM IND 1 MEM IND 2 MEMO BUTTON MEMO POS 1 MEMO POS 2 MEMO SET MICU ORG/ WIRE P/W COUNT PNK WIRE POSITION POSITION 1 INDICATOR POSITION 2 INDICATOR REAR UP-DOWN SWITCH RECLINE SWITCH RED WIRE SLIDE FRONT SWITCH UP-DOWN SWITCH VBU VMP DR WHT WIRE YEL WIRE
