Acura TL IV (2008-2011) Cooling fan circuit

A/C CONDENSER FAN MOTOR (LOWER MIDDLE FRONT OF ENGINE COMPT) A/C CONDENSER FAN RELAY A/C DIODE A A/C DIODE B A/C PRESSURE SENSOR (RIGHT REAR OF ENGINE COMPT) AIR CONDITIONING SYSTEM BLK (OR BRN) WIRE BLK WIRE BLK/BRN WIRE BLU (OR RED) WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT COMPUTER B CAN LO B CAN HI A/C PRESSURE SENS DATA LINES PNK SYSTEM WIRE COMPUTER DATA LINES SYSTEM ECT SENS 2 IN ECT SENSOR 1 ECT SENSOR 2 (UNDER FRONT OF ENGINE COMPT) F-CAN COMM SIG FAN CONTROL RELAY FUSE 7 GRN WIRE GRN) (OR YEL/ WIRE GRN/YEL WIRE GROUND (BEHIND MIDDLE OF DASH) 1 2 7 8 11 COMMON SENS GND HOT AT ALL TIMES HOT AT ALL TIMES MULTI FUSE-3 SUB FAN MOTOR HOT IN ON DRIVER'S UNDER-DASH FUSE FUSE/RELAY BOX (UNDER LEFT END OF DASH) HOT W/ PGM-FI SUB RELAY ENERGIZED LT GRN WIRE PCM (RIGHT SIDE OF ENGINE COMPT) PNK WIRE RADIATOR FAN RELAY REAR WINDOW DEFOGGER RELAY FUSE 21 RED WIRE RED/WHT WIRE RLY CTRL (FANH) RLY CTRL (FANL) SENS GND UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) W/ SH-AWD W/O SH-AWD WHT WIRE YEL WIRE
