Acura TL IV (2008-2011) switch/front passenger's air bag cut-off indicator Wiring diagram
This page shows the only wiring diagram for the component.switch/front passenger's air bag cut-off indicator, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch/front passenger's air bag cut-off indicator (1 of 1)
1 8 ILL- ILL+
10 12 ILL-LCD ILL+
23 11 12 ILL+ ILL-LED ILL-LCD
A/T GEAR POSITION INDICATOR PANEL LIGHT
AUDIO UNIT (W/O NAVIGATION)
AUDIO-HVAC DISPLAY UNIT
AUDIO/NAVIGATION SWITCH PANEL
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BRIGHTENING SWITCH DIMMING SWITCH
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
CONSOLE BOX LIGHT
DASH LIGHTS DRIVER'S FOOTWELL BRIGH- TNESS CONT- ROLLER LIGHT
DRIVER'S CLIMATE CONTROL SWITCH
DRIVER'S JUNCTION BOX 2 (BEHIND LEFT SIDE OF DASH)
DRIVER'S SEAT HEATER SWITCH
FRONT PASSENGER'S CLIMATE CONTROL SWITCH
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 2
FUSE 6
GLOVE BOX LIGHT
GND (MICU -S)
GND (MICU-P)
GRY WIRE
HAZARD WARNING
HEADLIGHT WASHER SWITCH (IF EQUIPPED)
HOT AT ALL TIMES
ILL+ GND
ILL+ ILL-LED
LT BLU WIRE
MOONROOF SWITCH
ORG/ WIRE
PASSENGER'S MICU
PASSENGER'S MICU TAILLIGHT CONTROL CIRCUIT
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
PPL
REAR INDIVI- DUAL MAP LIGHTS
RED WIRE
RIGHT END OF DASH)
ROOF CONSOLE
SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
VSA OFF SWITCH
W/ NAVIGATION
W/O NAVIGATION
Go to component -> Instrument illumination circuit (2 of 2) -> SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
