Acura TL IV (2008-2011) str sens str str svcc gnd Wiring diagram
This page shows the only wiring diagram for the component.str sens str str svcc gnd, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram str sens str str svcc gnd (1 of 1)
ABS IND.
BLK WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE SYSTEM IND
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 2 (BEHIND LEFT SIDE OF DASH)
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 15
FUSE 20
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
LT GRN WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (ON PARK BRAKE LEVER BRACKET)
PPL
PPL 4
RED WIRE
STEERING ANGLE SENSOR (W/O SH-AWD) (ON STEERING COLUMN)
STR SENS STR STR SVCC GND
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VSA ACTIVATION IND
VSA OFF SWITCH
VSA SYSTEM IND
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> STR SENS STR STR SVCC GND
