Acura TL IV (2008-2011) ppl sync led fr led dr ind pwm Wiring diagram
This page shows the only wiring diagram for the component.ppl sync led fr led dr ind pwm, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl sync led fr led dr ind pwm (1 of 1)
A/C COMPRESSOR
A/C COMPRESSOR CLUTCH
A/C CONDENSER FAN MOTOR (LOWER MIDDLE FRONT OF ENGINE COMPT)
BLK WIRE
BLOWER MOTOR (UNDER RIGHT SIDE OF DASH)
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLIMATE CONTROL UNIT
DEF
DEF-LED
DRIVER'S MODE CONTROL MOTOR (UNDER LEFT SIDE OF DASH)
FR LED (+)
FRONT PASSENGER'S CLIMATE CONTROL SWITCH
FRONT PASSENGER'S MODE CONTROL MOTOR (BEHIND GLOVE BOX)
FUSE FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
GRN WIRE
GRY WIRE
HOT IN ON
IND PWM
LT BLU WIRE
LT GRN WIRE
M-DEF
M-VENT
MODE 1
MODE 2
MODE 3
MODE 4
ORG/ WIRE
PASSENGER'S UNDER-DASH
PNK WIRE
PPL
PPL SYNC LED FR LED DR IND PWM
RED WIRE
RED/BLK WIRE
S-COM
SYNC LED
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> PPL SYNC LED FR LED DR IND PWM
