Acura TL IV (2008-2011) power window master switch control unit Wiring diagram
This page shows the only wiring diagram for the component.power window master switch control unit, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window master switch control unit (1 of 1)
33 35 14 2 32 B-CAN LO B-CAN HI PNK WIRE
B CAN B CAN HI LO
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S MICU
FUEL FILL DOOR OPENER RELAY
FUEL FILL DOOR OPENER SOLENOID (LEFT SIDE OF TRUNK)
FUEL FILL DOOR OPENER SWITCH
FUEL LID ACT
FUEL LID SG
FUSE 16
HOT AT ALL TIMES FUSE 25
HOT IN ON DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
JUNCTION CONNECTOR
LT GRN WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH CONTROL UNIT
TRUNK LID OPENER/ FUEL FILL DOOR OPENER SWITCH
YEL WIRE
Go to component -> Fuel door release circuit -> POWER WINDOW MASTER SWITCH CONTROL UNIT
