Acura TL IV (2008-2011) power mirror defogger switch power mirror defogger ind Wiring diagram
This page shows the only wiring diagram for the component.power mirror defogger switch power mirror defogger ind, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power mirror defogger switch power mirror defogger ind (1 of 1)
27 33 35 PNK UART B-CAN LO B-CAN HI WIRE
B-CAN B-CAN GND CLIMATE CONTROL UNIT HI LO
BLK WIRE
BLU WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL UNIT FRONT PASSENGER'S POWER WINDOW SWITCH
CONTROL UNIT POWER WINDOW MASTER SWITCH
DEFOGGER LEFT POWER MIRROR (FRONT OF DRIVER'S DOOR)
DEFOGGER RIGHT POWER MIRROR
DRIVER'S UNDER-DASH
FUSE 13
FUSE 16
FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
FUSE/RELAY BOX (UNDER LEFT END OF DASH)
GRN WIRE
HEAT (+)
HOT AT ALL TIMES
HOT IN ON
LT GRN WIRE
ORG/ WIRE
PASSENGER'S UNDER-DASH
PNK COMPUTER DATA LINES SYSTEM WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER MIRROR DEFOGGER SWITCH POWER MIRROR DEFOGGER IND
RIGHT END OF DASH)
UART
VMPAS
YEL WIRE
Go to component -> Heated mirrors circuit -> POWER MIRROR DEFOGGER SWITCH POWER MIRROR DEFOGGER IND
