Acura TL IV (2008-2011) left side turn signal Wiring diagram
This page shows the only wiring diagram for the component.left side turn signal, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side turn signal (1 of 1)
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DEFOGGER
DEFOGGER SYSTEM
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
FUSE 12
FUSE 16
FUSE 24
GND GND GND GND
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
LEFT POWER MIRROR (FRONT OF DRIVER'S DOOR)
LEFT SIDE TURN SIGNAL
LEFT/ RIGHT MOTOR
LT BLU WIRE
LT GRN WIRE
MEM IND 1
MEM IND 2
MEMO POS 1
MEMO POS 2
MEMO SET
MICU
ORG/ WIRE
ORG/WHT WIRE
P/W COUNT
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RIGHT POWER MIRROR (FRONT OF FRONT PASSENGER'S DOOR)
RIGHT SIDE TURN SIGNAL
SWING TILT
TILT SWING
UP/ DOWN MOTOR
VBU
VMP DR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> LEFT SIDE TURN SIGNAL
