Acura TL IV (2008-2011) left left brake front light/ turn tail signal/ light parking light Wiring diagram
This page shows the only wiring diagram for the component.left left brake front light/ turn tail signal/ light parking light, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left left brake front light/ turn tail signal/ light parking light (1 of 1)
A/C CONDENSER FAN RELAY
AS LIGHT
BLU WIRE
DOOR DOOR LOCK UNLOCK RELAY RELAY
DR FUSE BOX
DR LIGHT MAIN FUSE
DRIVER'S MICU TAIL LIGHT FOG LIGHT CONTROL CONTROL CIRCUIT CIRCUIT
ELD UNIT
FROM MULTI-FUSE 1 (DIAGRAM 1 OF 6)
FUEL FILL DRIVER'S DOOR OPENER DOOR UNLOCK RELAY RELAY
FUSE 14 (NOT USED)
FUSE 19 FUSE 21
FUSE 20
FUSE 22
FUSE 24
FUSE 25
FUSE 26 FUSE 27
FUSE 28
FUSE 29
FUSE 30
FUSE 31 (NOT USED)
FUSE 4
FUSE 5 (NOT USED)
FUSE 6 (NOT USED)
GRN WIRE
HIGH BEAM CONTROL CIRCUIT
IG MAIN MAIN FUSE FUSE
LEFT FOG LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT HEADLIGHT
LEFT LEFT BRAKE FRONT LIGHT/ TURN TAIL SIGNAL/ LIGHT PARKING LIGHT
LEFT REAR POWER WINDOW RELAY
LOW BEAM CONTROL CIRCUIT
LT BLU WIRE
MAIN FAN MOTOR FUSE
MOONROOF POWER SEAT CONTROL CONTROL UNIT UNIT/ MOTOR
MULTI FUSE 3
PNK WIRE
POWER WINDOW MASTER SWITCH
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/BLK WIRE
RIGHT REAR SIDE MARKER LIGHT
STARTER CUT RELAY 1
SUB FAN FUSE
TO FUSE 15 (DIAGRAM 3 OF 6)
TO FUSE 23 (DIAGRAM 6 OF 6)
TO IGNITION SWITCH (DIAGRAM 5 OF 6)
TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 6)
TPMS CONTROL MODULE
TRUNK LID OPENER RELAY
W/ SH-AWD
W/O SH-AWD
WHT WIRE
WINDSHIELD WIPER RELAY
WIPER MOTOR FUSE
YEL WIRE
Go to component -> Power distribution circuit, without keyless access (2 of 6) -> LEFT LEFT BRAKE FRONT LIGHT/ TURN TAIL SIGNAL/ LIGHT PARKING LIGHT
