Acura TL IV (2008-2011) k-line scty remote sw Wiring diagram
This page shows the only wiring diagram for the component.k-line scty remote sw, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram k-line scty remote sw (1 of 1)
AM/FM ANTENNA AMPLIFIER (IN RIGHT "C" PILLAR)
AUDIO REMOTE SWITCH/HFL-VOICE CONTROL SWITCH
AUDIO UNIT
BLK WIRE
BLU WIRE
BOX)
BRN WIRE
CABLE REEL (IN STEERING COLUMN)
CENTER JUNCTION BOX (UNDER LEFT
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CHANNEL DOWN SWITCH
CHANNEL UP SWITCH
COMPUTER DATA LINES SYSTEM
CTR PRE+ SUR L PRE- SUR R PRE- SUR PRE SH
CTR PRE- SUBW PRE-
FL PRE- FR PRE-
FUSE
FUSE 15
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON DRIVER'S UNDER-DASH FUSE 16 FUSE/RELAY BOX (UNDER LEFT END OF DASH)
ILL-LED
K-LINE SCTY REMOTE SW
LT BLU WIRE
LT GRN WIRE
MAIN GND ILL+
MODE SWITCH
NAVIGATION SYSTEM
NCA WIRE
PASSENGER'S MICU
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (BEHIND
PNK REMOTE SW SWD +B FR PRE- FR PRE+ FR PRE SH FL PRE SH FL PRE- FL PRE+ +B WIRE
PNK WIRE
PPL
PRE SH
REAR WINDOW AM SIGNAL FM SIGNAL WINDOW WINDOW ANTENNA ANTENNA
RED WIRE
RF IN RF SH ANT +B
SCTY
SIDE OF DASH)
STEERING WHEEL)
STEREO AMPLIFIER (RIGHT SIDE OF TRUNK)
SUBW PRE+ CTR/SWF
SUBW PRE- CTR PRE-
SUR L PRE+ SUR R PRE+ DPL 2 ON/OFF
SUR L PRE- SUR R PRE-
SW B
UNDER-HOOD FUSE/RELAY BOX
VOLUME DOWN SWITCH
VOLUME UP SWITCH
W/ SH-AWD
W/O SH-AWD
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation (1 of 3) -> K-LINE SCTY REMOTE SW
