Acura TL IV (2008-2011) head headlight switch combination light switch Wiring diagram
This page shows the only wiring diagram for the component.head headlight switch combination light switch, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram head headlight switch combination light switch (1 of 1)
+B BACKUP
17 16 GND NAVI ILL+
AUDIO REMOTE SWITCH/ HFL-VOICE CONTROL
AUDIO- NAVIGATION UNIT
AUTO
B-CAN LO
BLK WIRE
BLU WIRE
BOX 1 (BEHIND LEFT SIDE OF DASH)
BRN WIRE
CABLE REEL (B: IN STEERING COLUMN) (C: IN STEERING WHEEL)
COMPUTER COMPUTER DATA LINES DATA LINES SYSTEM SYSTEM
COMPUTER DATA LINES SYSTEM
CONTROLLER AREA NETWORK CONTROLLER POWER SUPPLY CIRCUIT/
CRUISE CONTROL COMBINATION/ SELECT/ RESET/ INFORMATION SWITCH
DAY LT H/L SMALL GND OFF (LIGHT) SW
DISPLAY
DRIVER'S JUNCTION
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/
FUSE 12
FUSE 15
GAUGE CONTROL MODULE
GND (MICU -S)
GND (MICU-P)
GND NAVI ILL+
GRY WIRE
H/L LO B-CAN SW SW HI
HEAD HEADLIGHT SWITCH COMBINATION LIGHT SWITCH
HEAD OFF PARK AUTO
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
INFORMATION
LT BLU WIRE
LT GRN WIRE
METER
MULTI-
NAVIGATION DISPLAY UNIT
NETWORK TRANSCEIVER BODY CONTROLLER AREA
OFF PARK
ORG/ WIRE
PADDLE SHIFTER + (UPSHIFT SWITCH)
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
PNK WIRE
PPL
RED WIRE
RELAY BOX (UNDER LEFT END OF DASH)
SHIFT INDICATOR DRIVER CIRCUIT
STEERING WHEEL)
SWITCH (W/O NAVIGATION) AUDIO REMOTE SWITCH/ HFL-NAVIGATION
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VOICE CONTROL SWITCH
WHT WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> HEAD HEADLIGHT SWITCH COMBINATION LIGHT SWITCH
