Acura TL IV (2008-2011) hazard warning switch/front passenger's cut-off indicator Wiring diagram
This page shows the only wiring diagram for the component.hazard warning switch/front passenger's cut-off indicator, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard warning switch/front passenger's cut-off indicator (1 of 1)
A/T GEAR POSITION INDICATOR PANEL LIGHT
AUDIO NAVIGATION SWITCH PANEL (W/ NAVIGATION)
AUDIO REMOTE SWITCH, HFL-VOICE CONTROL SWITCH
AUDIO UNIT
AUDIO-HVAC DISPLAY UNIT
BRN WIRE
CABLE REEL
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CLIMATE CONTROL UNIT
CONSOLE DRIVER'S BOX CLIMATE LIGHT CONTROL SWITCH
CRUISE CONTROL COMBINATION/ SELECT/RESET/ INFORMATION SWITCH
DASH LIGHTS BRIGHTNESS CONTROLLER
DRIVER'S JUNCTION BOX 2 (BEHIND LEFT SIDE OF DASH)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S VSA OFF FOOTWELL SWITCH LIGHT
FOG LIGHT CONTROL CIRCUIT
FROM DRIVER'S UNDER-DASH FUSE/ RELAY BOX (DIAGRAM 2 OF 6)
FRONT PASSENGER'S CLIMATE CONTROL SWITCH
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 1
FUSE 2
FUSE 3
FUSE 4
FUSE 5 (NOT USED) PASSENGER'S MICU
FUSE 6
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH/FRONT PASSENGER'S CUT-OFF INDICATOR
HEADLIGHT WASHER SWITCH (IF EQUIPPED)
HIGH BEAM CONTROL CIRCUIT
JUNCTION
LOW BEAM CONTROL CIRCUIT
LT BLU WIRE
MOONROOF SWITCH
ORG/ WIRE
REAR INDIVIDUAL MAP LIGHTS
RIGHT FOG LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
RIGHT HEADLIGHT
ROOF CONSOLE
STEERING WHEEL)
TAIL LIGHT CONTROL CIRCUIT
W/O NAVIGATION
Go to component -> Power distribution circuit, without keyless access (4 of 6) -> HAZARD WARNING SWITCH/FRONT PASSENGER'S CUT-OFF INDICATOR
