Acura TL IV (2008-2011) gauge control Wiring diagram
This page shows the only wiring diagram for the component.gauge control, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gauge control (1 of 1)
+B BACKUP
+B SMART
B-CAN HI
B-CAN LO
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
COMPUTER DATA LINES SYSTEM
DCK
DIN/DOUT
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH)
ELE KEY SW
ELECTRIC STEERING LOCK CONTROL UNIT (IN STEERING COLUMN)
ENGINE START/STOP SWITCH
ESL PWR
ESL SW B
ESL SW C
ESL SW D
ESL SWB
GAUGE CONTROL
GRN WIRE
GRY WIRE
H BRAKE SW
HBRAKE SW
IGN TRX
IGN TX
IMOCD (S-NET)
K LINE
KEYLESS ACCESS INDICATOR
KEYLESS ACCESS SYSTEM MODE SWITCH
LT BLU WIRE
LT GRN WIRE
MODULE
MTR CNT
MTR CUT 1
MTR CUT 2
ORG/ WIRE
PCM (RIGHT SIDE OF ENGINE COMPT)
PCU KEY
PNK PNK WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
RED WIRE
REMOTE SLOT CONTROL UNIT (BEHIND RIGHT SIDE OF DASH)
RIGHT END OF DASH)
SCS
SECURITY INDICATOR
SECURITY INDICATOR BLINKING CIRCUIT
SLOT SW FULL
SLOT SW HALF
SLOT SW LOCK
SOL +
VOUT SLOT
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit, with keyless access (3 of 5) -> GAUGE CONTROL
