Acura TL IV (2008-2011) front passenger's door lock knob switch wiring diagram
This page shows the only wiring diagram for the component.front passenger's door lock knob switch, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front passenger's door lock knob switch wiring diagram (1 of 1)
B-CAN
B-CAN LO
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DOOR LOCK SWITCH
DOOR LOCK SWITCH LOCK LIGHT
DOOR LOCK SWITCH UNLOCK LIGHT
DRIVER'S DOOR SWITCH (IN LEFT "B" PILLAR)
FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
FRONT PASSENGER'S DOOR SWITCH (IN RIGHT "B" PILLAR)
FRONT PASSENGER'S POWER WINDOW SWITCH
GRN WIRE
KNOB
KNOB UN LK PPL
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
LOCK
LOCK KNOB
LT BLU WIRE
LT GRN WIRE
MAIN ILLUMINATION
PNK COMPUTER DATA LINES SYSTEM UART WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RIGHT END OF DASH)
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
SECURITY HOOD SWITCH (INTEGRAL TO ENGINE COMPT HOOD LATCH ASSEMBLY)
TRUNK LID SPOILER SWITCH
UART
UNLOCK
VMP AS
VMP DR
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, with keyless access (2 of 5) -> FRONT PASSENGER'S DOOR LOCK KNOB SWITCH
