Acura TL IV (2008-2011) fob lock solenoid Wiring diagram
This page shows the only wiring diagram for the component.fob lock solenoid, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fob lock solenoid (1 of 1)
AUDIO UNIT
AUDIO- NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 2 (BEHIND LEFT SIDE OF DASH)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
FC IC
FOB LOCK SOLENOID
FUSE 18
FUSE 9
FUSE FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
KEY LT-
KEYLESS ACCESS JUNCTION BOX (UNDER LEFT SIDE OF DASH)
LF ANTENNA
LT BLU WIRE
LT GRN WIRE
NAVIGATION DISPLAY UNIT
ORG/ WIRE
PARKING BRAKE SWITCH (ON PARK BRAKE LEVER BRACKET)
PASSENGER'S MICU
PNK PNK WIRE
PNK WIRE
PPL
PPL PNK WIRE
PPL PPL
RED WIRE
REMOTE SLOT
SCTY
UNDER- HOOD
VOUT SLOT
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit, with keyless access (4 of 5) -> FOB LOCK SOLENOID
