Acura TL IV (2008-2011) brake light shield dlc Wiring diagram
This page shows the only wiring diagram for the component.brake light shield dlc, which is found in the car Acura TL IV (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake light shield dlc (1 of 1)
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLU WIRE
BRAKE LIGHT SHIELD DLC
BRN WIRE
CABLE REEL (IN STEERING COLUMN)
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR UNLOCK RELAY
DRIVER'S FRONT VANITY PASSENGER'S MIRROR VANITY LIGHT MIRROR LIGHT
DRIVER'S POWER WINDOW MOTOR
DRIVING POSITION MEMORY SWITCH
FRONT PASSENGER'S POWER
GAUGE CONTROL MODULE
GND GND (MICU-S) (MICU-S)
GRY WIRE
HEADLIGHT WASHER SWITCH (IF EQUIPPED)
HFL- MOONROOF NAVIGATION SWITCH MICROPHONE (IF EQUIPPED)
HIGH MOUNT
JUNCTION CONNECTOR
LEFT POWER MIRROR
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
MOONROOF CONTROL UNIT/MOTOR SHIELD
PADDLE SHIFTER (-) (DOWNSHIFT
PASS- ENGER'S MICU GND MICU-S
POWER MIRROR CONTROL UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
POWER WINDOW MOTOR SHIELD
PPL
REAR INDIVIDUAL MAP LIGHTS
RED WIRE
ROOF CONSOLE
STEERING ANGLE SENSOR (W/ SH-AWD)
STEERING WHEEL)
SWITCH
TRUNK LID OPENER/FUEL FILL DOOR OPENER SWITCH
VSA OFF SWITCH
WINDOW MOTOR
WINDOW SWITCH
Go to component -> Ground distribution circuit (4 of 4) -> BRAKE LIGHT SHIELD DLC
