Acura TL IV (2008-2011) 33 35 36 computer data lines pnk ppl system Wiring diagram

33 35 36 COMPUTER DATA LINES PNK PPL SYSTEM WIRE B CAN B CAN HI LO B-CAN LO B-CAN HI RR L SUB SW DOWN BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL UNIT) DOWN DOWN VMP DR ILLUMI DRIVER'S DOOR KEY CYLINDER SWITCH DRIVER'S DOOR LOCK ACTUATOR/KNOB DRIVER'S JUNCTION BOX 1 (BEHIND LEFT SIDE OF DASH) DRIVER'S MICU DRIVER'S POWER WINDOW MOTOR (CENTER OF DRIVER'S DOOR) DRIVER'S SWITCH 0) OFF 1) UP 2) DOWN 3) AUTO DOWN 4) AUTO UP DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) FRONT PASSENGER'S SWITCH FUSE 12 FUSE 16 FUSE 22 FUSE 24 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START INTERIOR LIGHTS SYSTEM COMPUTER PNK DATA LINES SYSTEM 28 29 PNK WIRE LEFT REAR POWER WINDOW RELAY LEFT REAR SWITCH LOCK LOCK UN- LOCK LT BLU WIRE LT GRN WIRE MAIN SWITCH METER GND (MICU-S) P/W RR L RLY CL- PNK WIRE POWER WINDOW MASTER SWITCH POWER WINDOW MASTER SWITCH ILLUMINATION PPL PULSER RED WIRE RIGHT REAR SWITCH RR R SUB SW DOWN RR R SUB SW UP PLSA RR L SUB SW UP SVCC UP PLSB SWITCH/KEY CYLINDER SWITCH UART UNDER-HOOD FUSE/RELAY FUSE 15 BOX (LEFT REAR OF ENGINE COMPARTMENT) UNLOCK VBU WHT WIRE YEL WIRE
