Starting circuit, m/t for Acura TL III facelift (2006-2008)
Starting circuit, m/t
AUXILIARY UNDER-DASH FUSE HOLDER (UNDER LEFT SIDE OF DASH)
BATTERY
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH INTERLOCK SWITCH (NEAR CLUTCH PEDAL)
ECM (BEHIND CENTER OF DASH)
ELD UNIT
FUSE
FUSE 36
IGNITION SWITCH
LOCK
LT BLU WIRE
LT GRN WIRE
MULTI- FUSE 22
MULTI- FUSE 23
PL IN HD IN
STARTER
STARTER CUT RELAY 1 (UNDER LEFT SIDE OF DASH)
STARTER MOTOR
STARTER SOLENOID
STARTER SWITCH SIGNAL (STS)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
