Horn circuit for Acura TL III facelift (2006-2008)
Horn circuit
BLK WIRE
BLK/GRN WIRE
BLU/RED WIRE
CABLE REEL REEL (B: ON STEERING COLUMN) (C: ON STEERING WHEEL)
CONTROL BLOCK
CRUISE CONTROL COMBINATION SWITCH
GRN/YEL WIRE
HIGH HORN (BEHIND LEFT SIDE OF FRONT BUMPER)
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES FUSE 13
LOW HORN (BEHIND RIGHT SIDE OF FRONT BUMPER)
NCA WIRE
RELAY CONTROL MODULE
STEERING WHEEL)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
