Backup lamps circuit, a/t for Acura TL III facelift (2006-2008)
Backup lamps circuit, a/t
ATP-R
AUTOMATIC DIMMING INSIDE MIRROR
BACK LT-
BLK WIRE
ENGINE CONTROLS SYSTEM
FUSE 21
GRN WIRE
GRY WIRE
HOT IN ON OR START
JUNCTION
JUNCTION CONNECTOR
LEFT BACK-UP LIGHT
MICU
NAVIGATION UNIT (IF EQUIPPED) (IN TRUNK, BELOW LEFT SIDE OF PACKAGE TRAY)
POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
RIGHT BACK-UP LIGHT
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
WHT WIRE
