Car Wiring Diagrams for Data link connector circuit for Acura TL III facelift (2006-2008)

AT LEFT REAR OF TRUNK) AUDIO UNIT BLK WIRE BRN WIRE DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) DIAG FUSE 8 (LEFT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE HIGH/LOW BUS CIRCUIT HOT AT ALL TIMES IMMOBILIZER CONTROL UNIT- RECEIVER (ON RIGHT SIDE OF STEERING COLUMN) JUNCTION CONNECTOR K LINE LT BLU WIRE LT GRN/BLK WIRE MES CONNECTOR MES IN SCS K-LINE MICU MICU SERVICE CHECK CONNECTOR RED WIRE RED/WHT WIRE SCS SRS UNIT (UNDER LOWER MIDDLE OF DASH) TPMS CONTROL UNIT (BEHIND LEFT REAR SEAT BACK) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX VSA MODULATOR CONTROL UNIT (ON RIGHT SIDE OF ENGINE COMPT) WEN ECM/PCM (BEHIND CENTER OF DASH) WHT WIRE WHT/GRN WIRE YEL WIRE
