Acura TL III facelift (2006-2008) shift interlock system rvs Wiring diagrams

A/F SENSOR RELAY ACTIVE NOISE CONTROL UNIT (TYPE S) (UNDER MIDDLE OF DASH) AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM COMPUTER DATA LINES SYSTEM IMOCD BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BRAKE PEDAL POSITION SWITCH (NEAR BRAKE PEDAL) BRN WIRE BRN/YEL WIRE CAN L CAN-H SCS PSPSW ELD COMPUTER DATA LINES SYSTEM CLUTCH PEDAL POSITION SWITCH (NEAR CLUTCH PEDAL) COMPUTER DATA LINES SYSTEM WEN COOLING FANS SYSTEM ECM (BEHIND CENTER OF DASH) FP- FPC FPCD FTP CRMCLS TYPE S FUEL PUMP FUEL PUMP CONTROL MODULE (TYPE S) (LEFT SIDE OF TRUNK) FUEL TANK PRESSURE (FTP) SENSOR (UNDER LEFT REAR OF VEHICLE) FUEL TANK UNIT (MIDDLE FRONT OF TRUNK) FUSE FUSE 19 FUSE 23 FUSE 4 GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX FUSE (LEFT REAR OF ENGINE COMPT) HOT IN ON OR START IGNITION COIL RELAY IMOFPR ETCSRLY AFSHTCR MRLY FAN-L FPC BKSW BKSWNC VSV VSSOUT LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE NEP PGM-FI MAIN RELAY 1 PGM-FI MAIN RELAY 2 PNK PPL PNK WIRE PNK WIRE PSP SWITCH (RIGHT SIDE OF ENGINE) RED WIRE RED/WHT WIRE SHIFT INTERLOCK SYSTEM RVS TYPE S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/WHT WIRE

A/F SENSOR RELAY ACTIVE NOISE CONTROL UNIT (TYPE S) (UNDER MIDDLE OF DASH) AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM COMPUTER DATA LINES SYSTEM IMOCD BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BRAKE PEDAL POSITION SWITCH (NEAR BRAKE PEDAL) BRN WIRE BRN/YEL WIRE CAN L CAN-H SCS PSPSW ELD COMPUTER DATA LINES SYSTEM CLUTCH PEDAL POSITION SWITCH (NEAR CLUTCH PEDAL) COMPUTER DATA LINES SYSTEM WEN COOLING FANS SYSTEM ECM (BEHIND CENTER OF DASH) FP- FPC FPCD FTP CRMCLS TYPE S FUEL PUMP FUEL PUMP CONTROL MODULE (TYPE S) (LEFT SIDE OF TRUNK) FUEL TANK PRESSURE (FTP) SENSOR (UNDER LEFT REAR OF VEHICLE) FUEL TANK UNIT (MIDDLE FRONT OF TRUNK) FUSE FUSE 19 FUSE 23 FUSE 4 GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX FUSE (LEFT REAR OF ENGINE COMPT) HOT IN ON OR START IGNITION COIL RELAY IMOFPR ETCSRLY AFSHTCR MRLY FAN-L FPC BKSW BKSWNC VSV VSSOUT LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE NEP PGM-FI MAIN RELAY 1 PGM-FI MAIN RELAY 2 PNK PPL PNK WIRE PNK WIRE PSP SWITCH (RIGHT SIDE OF ENGINE) RED WIRE RED/WHT WIRE SHIFT INTERLOCK SYSTEM RVS TYPE S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/WHT WIRE
