Acura TL III facelift (2006-2008) display panel control unit hands freelink control unit Wiring diagram
This page shows the only wiring diagram for the component.display panel control unit hands freelink control unit, which is found in the car Acura TL III facelift (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram display panel control unit hands freelink control unit (1 of 1)
A/T
ACC CUT RELAY (A/T) (UNDER LEFT SIDE OF DASH)
AUDIO UNIT ACURALINK CONTROL UNIT (XM RECEIVER) PCM
AUXILIARY UNDER-DASH FUSE HOLDER (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
DISPLAY PANEL CONTROL UNIT HANDS FREELINK CONTROL UNIT
DOOR MULTIPLEX CONTROL UNIT
FROM FUSE 12 (DIAGRAM 1 OF 5)
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 26
FUSE 27
FUSE 28
FUSE 32
FUSE 33
FUSE 36
GRN WIRE
IGNITION SWITCH
JUNCTION CONNECTOR
LOCK
M/T
MICU
MOONROOF CONTROL UNIT SHIFT LOCK SOLENOID (A/T)
MULTI- FUSE 23
NAVIGATION UNIT
PCM
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
RED WIRE
RELAY (A/T) (UNDER LEFT SIDE OF DASH)
STARTER CUT RELAY 1
STARTER CUT RELAY 2
TO ACCESSORY POWER SOCKET RELAY (DIAGRAM
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 5)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 5)
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
USA
W/ NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> DISPLAY PANEL CONTROL UNIT HANDS FREELINK CONTROL UNIT
