Acura TL III facelift (2006-2008) controller area network Wiring diagram
This page shows the only wiring diagram for the component.controller area network, which is found in the car Acura TL III facelift (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram controller area network (1 of 1)
AT LEFT REAR OF TRUNK)
AUTOMATIC LIGHTING CONTROL UNIT (UNDER LEFT SIDE OF DASH)
AUTOMATIC LIGHTING SENSOR
B-CAN
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BODY
BRN WIRE
BRN/YEL WIRE
BUS -
CIRCUIT DRIVE
CIRCUIT DRIVE WARNING
CIRCUIT/CAN
CONTROLLER
CONTROLLER AREA NETWORK
CPU/FAIL SAFE
FOG LIGHT INDICATOR
FOG LIGHT RELAY UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH)
FUSE
GAUGE CONTROL MODULE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
JUNCTION
LEFT FOG LIGHT
LIGHTS ON INDICATOR
LT GRN WIRE
RED WIRE
RIGHT FOG LIGHT
SG-1
SG-2
SIG
SIO
SIP
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) MICU
VBU
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Headlights circuit, without drl (2 of 2) -> CONTROLLER AREA NETWORK
