Car Wiring Diagrams for Warning systems circuit for Acura SLX I (1995-1999)

BLK WIRE BLU WIRE BLU/YEL WIRE CLOCK [B] ROOM FUSE C-16 COMBINATION SWITCH DASH FUSE BOX DOOR LOCKS SYSTEM (W/ RKE) ENGINE CONTROLS SYSTEM FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) TAIL- LIGHT RELAY GRN WIRE GRY WIRE GRY/RED WIRE HEAD OFF HOT AT ALL TIMES HOT AT ALL TIMES FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) TAIL FUSE F-12 HOT IN ON OR START METER GAUGE FUSE C-10 IGNITION SWITCH KEY REMINDER SWITCH LEFT FRONT DOOR SWITCH (REAR OF LEFT FRONT DOOR) LEFT FRONT SEAT BELT SWITCH (IN LEFT FRONT SEAT BELT BUCKLE) LIGHTING SWITCH LT GRN WIRE METER ASSEMBLY PARK PNK WIRE PNK/BLU WIRE RED WIRE RKE: REMOTE KEYLESS ENTRY SEAT BELT WARNING INDICATOR LIGHT SEAT BELT, KEY,, LIGHT REMINDER BUZZER (RIGHT SIDE KICK PANEL) SUPPLEMENTAL RESTRAINTS SYSTEM WHT WIRE YEL WIRE
