Door lock circuit for Acura SLX I (1995-1999)
Door lock circuit
10 D-5 3 1 2 D-30
9 D-5
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
C-18 DOOR LOCK FUSE
C-4 ELEC. IGN. FUSE
C/B-2 (P/W, P/S, S/R) CB
CONTROL UNIT)
DASH FUSE BOX (BEHIND LEFT DASH SIDE TRIM PANEL)
DOOR LOCK SWITCH
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR LOCK ACTUATOR/SWITCH
LEFT FRONT DOOR LOCK KEY SWITCH
LEFT FRONT DOOR POWER WINDOW, LOCK SWITCH
LEFT REAR DOOR LOCK ACTUATOR/SWITCH
LOCK
LOCK RELAY
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/BLU WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
POWER WINDOW RELAY
POWER WINDOWS SYSTEM
RED WIRE
RIGHT FRONT DOOR LOCK ACTUATOR/SWITCH
RIGHT FRONT DOOR LOCK KEY SWITCH
RIGHT FRONT DOOR POWER WINDOW AND LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR/SWITCH
TAILGATE DOOR LOCK ACTUATOR/SWITCH
UNLOCK
UNLOCK RELAY
WHT WIRE
