Acura SLX I (1995-1999) turn light tail- light Wiring diagram
This page shows the only wiring diagram for the component.turn light tail- light, which is found in the car Acura SLX I (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn light tail- light (1 of 1)
1995 MODEL YEAR
1996 MODEL YEAR 1997 MODEL YEAR
ANTI-LOCK BRAKES
BLK WIRE
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
COMBINATION SWITCH
DASH FUSE BOX (BEHIND LEFT
DASH SIDE TRIM PANEL)
ENGINE CONTROLS
F-12 TAIL
F-4 H/LAMP-LH FUSE
FL-1 (MAIN)
FUSE
FUSE, RELAY BOX (RIGHT
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT) TAILLIGHT RELAY
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
G-8
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
H-12
H-39
HEAD OFF PARK
HEADLIGHTS
HIGH MOUNT STOP LIGHT
HOT AT ALL TIMES
HOT AT ALL TIMES C-14 STOP A/T CONT FUSE
LEFT REAR COMBINATION LIGHT ASSEMBLY
LICENSE PLATE LIGHT
LIGHTING RELAY
LIGHTING SWITCH
LT BLU WIRE
NCA WIRE
PNK/BLK WIRE
PPL/RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SIDE OF ENGINE COMPT)
STOP LIGHT SWITCH (ON BRAKE PEDAL SUPPORT)
TAIL- LIGHT
TRAILER CONNECTOR (BELOW LEFT REAR OF VEHICLE, BEHIND GROMMET)
TURN LIGHT
TURN LIGHT TAIL- LIGHT
W/ CRUISE CONTROL
W/O CRUISE CONTROL
WHT WIRE
WHT/BLU WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> TURN LIGHT TAIL- LIGHT
