Acura SLX I (1995-1999) chk trans ind ctrl Wiring diagram
This page shows the only wiring diagram for the component.chk trans ind ctrl, which is found in the car Acura SLX I (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram chk trans ind ctrl (1 of 1)
"ANTI-THEFT" INDICATOR
A/T OIL TEMPERATURE WARNING INDICATOR
A/T OIL TEMPERATURE, CHECK TRANSMISSION, ANTI-THEFT INDICATOR PANEL
ANTI-THEFT SYSTEM
BLU/YEL WIRE
C-1 A/T OIL TEMP IND CTRL
CHECK TRANSMISSION INDICATOR
CHK TRANS IND CTRL
DASH FUSE BOX (BEHIND LEFT KICK PANEL)
DOOR LOCK FUSE C-18
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN/BLK WIRE
LT GRN/WHT WIRE
METER GAUGE FUSE C-11
ORG/BLK WIRE
ORG/BLU WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (BELOW RADIO)
Go to component -> Indicator panel circuit -> CHK TRANS IND CTRL
