Power mirrors circuit, without defogger for Acura RSX I facelift (2004-2006)
Power mirrors circuit, without defogger
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
FUSE 14
GRN WIRE
HOT IN ON
LEFT
LEFT POWER MIRROR
LEFT RIGHT
LEFT/ RIGHT UP/ DOWN
POWER MIRROR SWITCH
POWER MIRROR SWITCH LIGHT
RED WIRE
RIGHT
RIGHT LEFT
RIGHT POWER MIRROR
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UP DOWN
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
