Acura RSX I facelift (2004-2006) side element sensor Wiring diagram
This page shows the only wiring diagram for the component.side element sensor, which is found in the car Acura RSX I facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side element sensor (1 of 1)
ANI-THEFT SYSTEM
BLK (OR GRN) WIRE
BLK (OR WHT/BLU) WIRE
BLK WIRE
BLU (OR GRN/ORG) WIRE
BLU (OR ORG/BLU) WIRE
BLU WIRE
BRN WIRE
DATA LINK CONNECTOR (ON RIGHT SIDE OF FRONT CONSOLE)
ENGINE CONTROLS SYSTEM
FUSE 9
GAUGE ASSEMBLY
GRN (OR ORG) WIRE
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT FRONT IMPACT SENSOR
ODUS GROUND
OPDS SENSOR (IN SEAT BACK)
OPDS UNIT (IN SEAT BACK)
ORG/ WIRE
PNK WIRE
RED (OR GRN) WIRE
RIGHT FRONT IMPACT SENSOR
SIDE AIR BAG CUT-OFF INDICATOR
SIDE AIR BAG INDICATOR POW SHIELD
SIDE ELEMENT SENSOR
SRS INDICATOR
SRS INDICATOR CIRCUIT
UNDER-DASH FUSE/RELAY BOX
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) FUSE 10
UPPER ELEMENT SENSOR UPPER ELEMENT SENSOR
WHT/RED (OR WHT) WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> SIDE ELEMENT SENSOR
