Acura RSX I facelift (2004-2006) set switch in Wiring diagram
This page shows the only wiring diagram for the component.set switch in, which is found in the car Acura RSX I facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram set switch in (1 of 1)
A/T
A/T COMMUNICATION
ACTUATOR CLUTCH CTRL
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL)
BRAKE SWITCH INPUT
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CABLE REEL (ON STEERING COLUMN)
CANCEL SWITCH
CLUTCH PEDAL POSITION SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL)
CRUISE CONTROL ACTUATOR (BEHIND RIGHT STRUT TOWER)
CRUISE CONTROL INDICATOR
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL SET/RESUME CANCEL SWITCH
CRUISE CONTROL SWITCH
CRUISE CONTROL SWITCH LIGHT
CRUISE CONTROL UNIT (UNDER LEFT SIDE OF DASH)
CRUISE CTRL MOTOR CLOSE
CRUISE CTRL MOTOR OPEN
CRUISE LAMP
ENGINE CONTROLS SYSTEM
FUSE 10
FUSE 7
GAUGE ASSEMBLY
GRN WIRE
GROUND
GRY/RED WIRE
HORN RELAY
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION INPUT
INHIBITOR SWITCH
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
M/T
MAIN
MULTIPLEX CONTROL UNIT HORN SW
ON INDICATOR
ORG/ WIRE
PCM (A/T) (UNDER RIGHT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
RESUME + SWITCH
RESUME SWITCH IN
SET SWITCH
SET SWITCH IN
STEERING WHEEL)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) FUSE 4
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
VEHICLE SPEED INPUT
VEHICLE SPEED OUTPUT CRUISE CONTROL SIG INPUT
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> SET SWITCH IN
