Acura RSX I facelift (2004-2006) reverse lockout solenoid Wiring diagram
This page shows the only wiring diagram for the component.reverse lockout solenoid, which is found in the car Acura RSX I facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reverse lockout solenoid (1 of 1)
A/F SENSOR RELAY
ALTERNATOR
BACK-UP LIGHT SWITCH SHIFT LOCK RELAY
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
CMP SENSOR A
CRUISE CONTROL UNIT CRUISE CONTROL MAIN SWITCH
ELD UNIT
EVAP CANISTER PURGE VALVE
EVAP CANISTER VENT SHUT VALVE
EXCEPT CANADA BASE
FROM FUSE 13 (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (DIAGRAM 1 OF 4)
FUSE 10
FUSE 17
FUSE 19 FUSE 20 FUSE 13
FUSE 22 FUSE 23
FUSE 4
FUSE 6
FUSE 9
GRN WIRE
HAZARD WARNING SWITCH SRS UNIT SECURITY CONTROL UNIT
IMMOBILIZER CONTROL UNIT RECEIVER PGM-FI MAIN RELAY 2
IMT (IMRC) SOLENOID VALVE
M/T A/T
MOONROOF CLOSE RELAY POWER WINDOW MASTER SWITCH
MOONROOF OPEN RELAY
MULTIPLEX CONTROL UNIT
NOT USED NOT USED
OPDS UNIT
ORG/ WIRE
PASSENGER'S POWER WINDOW SWITCH REAR WINDOW WIPER MOTOR
PNK W/ SECURITY WIRE
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
REVERSE LOCKOUT SOLENOID
SECONDARY
SRS UNIT
TYPE S
UNDERDASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
WIPER WASHER SWITCH GAUGE ASSEMBLY
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> REVERSE LOCKOUT SOLENOID
