Acura RSX I facelift (2004-2006) license plate light left backup light Wiring diagram
This page shows the only wiring diagram for the component.license plate light left backup light, which is found in the car Acura RSX I facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license plate light left backup light (1 of 1)
A/T
ATP -N
BLK WIRE
BLK/WHT WIRE
BLOWER POWER TRANSISTOR
CANADA
CLIMATE CONTROL UNIT
CLUTCH INTERLOCK SWITCH
CLUTCH PEDAL POSITION SWITCH
FRONT ACCESSORY POWER SOCKET
GAUGE ASSEMBLY
HATCH LATCH SWITCH HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT SHIELD HATCH LATCH SWITCH SHIELD
IGNITION KEY SWITCH/ KEY LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LICENSE PLATE LIGHT LEFT BACKUP LIGHT
M/T
MULTIPLEX CONTROL UNIT
NOISE CONDENSER/ HATCH LOCK ACTUATOR SHIELD
PASSENGER'S DOOR KEY CYLINDER SWITCH
PASSENGER'S DOOR LOCK KNOB SWITCH PASSENGER'S DOOR LOCK SWITCH
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER NOISE CONDENSER
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER MOTOR SHIELD
RED WIRE
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
SEAT HEATER RELAY SEAT HEATER SWITCH
SHIFT LOCK RELAY
TRAILER LIGHTING CONNECTOR
TRANSMISSION GEAR SELECTION SWITCH
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> LICENSE PLATE LIGHT LEFT BACKUP LIGHT
