Acura RSX I facelift (2004-2006) driver's airbag first, second inflator Wiring diagram
This page shows the only wiring diagram for the component.driver's airbag first, second inflator, which is found in the car Acura RSX I facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's airbag first, second inflator (1 of 1)
BLU WIRE
BLU/RED WIRE
CABLE REEL
DRIVER'S AIRBAG FIRST, SECOND INFLATOR
FUSE 7
HORN (BEHIND LEFT HEADLIGHT)
HORN RELAY
HORN SW
HORN SWITCH
HOT AT ALL TIMES
MULTIPLEX CONTROL UNIT
NCA WIRE
ORG/ WIRE
STEERING WHEEL)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
Go to component -> Horn circuit -> DRIVER'S AIRBAG FIRST, SECOND INFLATOR
