Acura RSX I facelift (2004-2006) combination light switch security control unit Wiring diagram
This page shows the only wiring diagram for the component.combination light switch security control unit, which is found in the car Acura RSX I facelift (2004-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination light switch security control unit (1 of 1)
ABS MODULATOR CONTROL UNIT (EXCEPT CANADA BASE)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRAKE PEDAL POSITION SWITCH AUDIO UNIT
CANADA
CANADA USA
COMBINATION LIGHT SWITCH SECURITY CONTROL UNIT
DATA LINK CONNECTOR
DRL CONTROL UNIT DRL RELAY
DRL CONTROL UNIT RIGHT HEADLIGHT
DRL DIODE
FROM UNDERHOOD FUSE/RELAY BOX (DIAGRAM 1 OF 4)
FUSE 10 FUSE 6
FUSE 15
FUSE 17
FUSE 31
FUSE 5
FUSE 7
FUSE 8
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
HAZARD WARNING SWITCH
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HORN RELAY
IGNITION COIL RELAY
IMMOBILIZER CONTROL UNIT RECEIVER GAUGE ASSEMBLY
KEYLESS RECEIVER UNIT
LEFT HEADLIGHT
MULTIPLEX CONTROL UNIT
PGM-FI MAIN RELAY 1
RED WIRE
RED/YEL WIRE
SECURITY CONTROL UNIT
SECURITY HORN RELAY
UNDERDASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERDASH MULTI FUSE/ RELAY BOX (BEHIND GLOVE BOX) FUSE 32
UNDERHOOD FUSE/ RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
USA
W/ SECURITY
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> COMBINATION LIGHT SWITCH SECURITY CONTROL UNIT
