Acura RSX I (2001-2004) transmission range switch clutch interlock switch Wiring diagram
This page shows the only wiring diagram for the component.transmission range switch clutch interlock switch, which is found in the car Acura RSX I (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission range switch clutch interlock switch (1 of 1)
A/T
A/T M/T
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CANADA
FROM IGNITION SWITCH (DIAGRAM 1 OF 4)
FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 4)
FRONT ACCESSORY POWER SOCKET
FUSE 18
FUSE 3
FUSE 8
GRN WIRE
LT GRN WIRE
MULTIPLEX CONTROL UNIT
REAR ACCESSORY POWER SOCKET
REAR ACCESSORY POWER SOCKET RELAY
RED WIRE
SHIFT LOCK SOLENOID
STARTER CUT RELAY
STARTER SOLENOID
TRANSMISSION RANGE SWITCH CLUTCH INTERLOCK SWITCH
UNDERDASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
USA
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> TRANSMISSION RANGE SWITCH CLUTCH INTERLOCK SWITCH
