Acura RSX I (2001-2004) rear window defog relay control Wiring diagram
This page shows the only wiring diagram for the component.rear window defog relay control, which is found in the car Acura RSX I (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defog relay control (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
CLIMATE CONTROL UNIT (ON CENTER OF DASH)
CONDENSER
FUSE 11
FUSE 14
GRD
HOT AT ALL TIMES
HOT IN ON
IGN IN
REAR WINDOW DEFOG RELAY CONTROL
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
WINDOW ANTENNA COIL (UNDER RIGHT SIDE OF REAR SHELF)
YEL/BLK WIRE
Go to component -> Rear defogger circuit -> REAR WINDOW DEFOG RELAY CONTROL
