Acura RSX I (2001-2004) passenger's door lock knob switch passenger's door lock switch Wiring diagram
This page shows the only wiring diagram for the component.passenger's door lock knob switch passenger's door lock switch, which is found in the car Acura RSX I (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's door lock knob switch passenger's door lock switch (1 of 1)
A/T
A/T SHIFT SWITCH
ATP -N
BLK WIRE
BLOWER POWER TRANSISTOR
CANADA
CLIMATE CONTROL UNIT
CLUTCH INTERLOCK SWITCH
CLUTCH PEDAL POSITION SWITCH
EXCEPT CANADA BASE
FRONT ACCESSORY POWER SOCKET
GAUGE ASSEMBLY
GLOVE BOX LIGHT
HATCH LATCH SWITCH
HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT SHIELD HATCH LATCH SWITCH SHIELD
IGNITION KEY SWITCH/ KEY LIGHT
LEFT BACKUP LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LICENSE PLATE LIGHT
M/T
MULTIPLEX CONTROL UNIT
NOISE CONDENSER/ HATCH LOCK ACTUATOR SHIELD
PASSENGER'S DOOR KEY CYLINDER SWITCH
PASSENGER'S DOOR LOCK KNOB SWITCH PASSENGER'S DOOR LOCK SWITCH
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER MOTOR SHIELD
RED WIRE
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT POWER MIRROR
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT RIGHT BRAKE LIGHT/ TAILLIGHT
SEAT HEATER RELAY SEAT HEATER SWITCH
SECURITY CONTROL UNIT
SECURITY HATCH LATCH SWITCH
SHIFT LOCK RELAY
TRAILER LIGHTING CONNECTOR
UNDERDASH FUSE/RELAY BOX
W/ SECURITY
Go to component -> Ground distribution circuit (3 of 3) -> PASSENGER'S DOOR LOCK KNOB SWITCH PASSENGER'S DOOR LOCK SWITCH
