Acura RSX I (2001-2004) left brake lights/ taillights Wiring diagram
This page shows the only wiring diagram for the component.left brake lights/ taillights, which is found in the car Acura RSX I (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left brake lights/ taillights (1 of 1)
BACK-UP LIGHT CIRCUIT
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (ON PEDAL BRACKET, ABOVE BRAKE PEDAL)
COMBINATION LIGHT SWITCH
CRUISE CONTROL UNIT
FUSE 19
FUSE 2
FUSE 5
FUSE 7
GAUGE ASSEMBLY
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HEAD LIGHT SWITCH
HEAD PARK
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
LEFT BRAKE LIGHTS/ TAILLIGHTS
LEFT FRONT PARKING LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TURN SIGNAL INDICATOR
OFF
OFF ON
ON ON OFF OFF
RED WIRE
RED/YEL WIRE
RIGHT BRAKE LIGHTS/ TAILLIGHTS
RIGHT FRONT PARKING LIGHT
RIGHT LICENSE REAR SIDE MARKER LIGHT PLATE LIGHT
RIGHT RIGHT REAR TURN SIGNAL LIGHT FRONT TURN SIGNAL LIGHT
RIGHT TURN SIGNAL INDICATOR
SECURITY CONTROL UNIT (IF EQUIPPED)
TAILLIGHT RELAY
TRAILER LIGHTING CONNECTOR (LEFT REAR CORNER OF TRUNK)
TURN LEFT
TURN RIGHT
TURN SIGNAL SWITCH
TURN SIGNAL/HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDERDASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDERHOOD FUSE/RELAY BOX (LEFT SIDE OF ENG COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Exterior lamps & trailer connector circuit -> LEFT BRAKE LIGHTS/ TAILLIGHTS
