Acura RSX I (2001-2004) grn/org Wiring diagrams

BLK WIRE BLU WIRE BLU/RED WIRE BRAKE FLUID LEVEL SWITCH BRAKE LEV SW B+ DAY LT (FR FOG) BRAKE SYSTEM INDICATOR COMBINATION LIGHT SWITCH DIMMER HIGH DIMMIER SWITCH DRL CONTROL UNIT (BEHIND LEFT SIDE OF DASH, ABOVE FUSE/RELAY BOX) DRL DIODE DRL H/L SW DRL INDICATOR DRL RELAY FLASH TO PASS SWITCH FUSE 10 FUSE 12 FUSE 15 FUSE 17 FUSE 19 FUSE 3 GAUGE ASSEMBLY GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE H/L HIGH H/L LOW HEAD HEAD OFF PARK HEADLAMP RELAY 1 HEADLAMP RELAY 2 HEADLIGHT SWITCH HIGH BEAM INDICATOR LIGHT HOT AT ALL TIMES HOT IN ON HOT IN ON OR START IGN 2 DAY LT LEFT HEADLIGHT LIGHTING RLY LO HI MPCS MULTIPLEX CONTROL UNIT OFF PARK PARKING BRAKE SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT HEADLIGHT SECURITY CONTROL UNIT (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) SECURITY SYSTEM UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLK/YEL WIRE DRIVER'S SEAT HEATER DRIVER'S SEAT HEATER SWITCH FUSE 14 FUSE 16 GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN ON INDICATORS OFF ON PASSENGER'S SEAT HEATER PASSENGER'S SEAT HEATER SWITCH RED WIRE RED/BLK WIRE SEAT HEATER RELAY (UNDER RIGHT SIDE OF DASH, BEHIND GLOVE BOX) SEAT HEATER SWITCH SEAT HEATER SWITCH LIGHT UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/YEL WIRE DATA LINK CONNECTOR (UNDER MIDDLE OF DASH) ECM/PCM (UNDER RIGHT SIDE OF DASH) ENGINE CONTROLS SYSTEM FUEL PUMP FUEL PUMP CTRL IMMOBILIZIER RELAY 1 CTRL POWER IMMOBILIZIER FUEL TANK UNIT (FRONT CENTER OF TRUNK) FUSE 17 FUSE 6 FUSE 9 GAUGE ASSEMBLY GRN WIRE GRN/ORG WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IMMOBILIZER CONTROL UNIT -RECEIVER (IN STEERING COLUMN COVER) IMMOBILIZER INDICATOR J/C NON-SAE NUMBER USED IN SERVICE MANUAL ORG/ WIRE PARKING BRAKE SWITCH PGM-FI MAIN RELAY 1 (BEHIND GLOVE BOX) PGM-FI MAIN RELAY 2 (BEHIND GLOVE BOX) POWER POWER GROUND GROUND RED WIRE RED/BLU WIRE RED/YEL WIRE UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

ABS INDICATOR CIRCUIT ABS INDICATOR LIGHT ANTI-LOCK BRAKES SYSTEM BEEPER BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CANADA CRUISE CONTROL INDICATOR LIGHT CRUISE CONTROL SYSTEM DASH LIGHTS BRIGHTNESS CONTROL CIRCUIT DRIVE CIRCUIT SPEEDOMETER DRL INDICATOR LIGHT ENGINE COOLANT TEMPERATURE GAUGE EXCEPT CANADA BASE FUEL GAUGE FUSE 10 FUSE 15 FUSE 9 (LEFT CORNER OF ENGINE COMPTARTMENT NEAR BATTERY) GAUGE ASSEMBLY GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE HEADLIGHT SYSTEM HOT AT ALL TIMES HOT IN ON OR START HOT WITH HEADLIGHT SWITCH IN HEAD OR PARK IMMOBILIZER CONTROL UNIT (STEERING COLUMN, NEAR LOCK CYLINDER) LEFT TURN SIGNAL INDICATOR LIGHT LOW OIL PRESSURE INDICATOR LIGHT MALFUNCTION INDICATOR LIGHT (MIL) METER MPCS SEFMJ ODOMETER/ TRIP DISPLAY PNK WIRE PNK/BLU WIRE POWER CIRCUIT RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT TURN SIGNAL INDICATOR LIGHT S-MATIC DISPLAY A/T SECURITY INDICATOR LIGHT SHIFT LOCK DIODE SIDE AIRBAG INDICATOR LIGHT SRS INDI- CATOR CIRCUIT SRS INDICATOR LIGHT TACHOMETER TO WASHER FLUID LEVEL INDICATOR LIGHT (DIAGRAM TRANSMISSION RANGE SWITCH (ON TRANSAXLE TRIP/RESET SWITCH UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX USA WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIPER/WASHER SYSTEM YEL WIRE YEL/BLK WIRE YEL/RED WIRE

A/T BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRAKE SYSTEM INDICATOR LIGHT CANADA CHARGING SYSTEM INDICATOR LIGHT D IND DIMMING CIRCUIT DOOR/HATCH INDICATOR LIGHT DRIVE CIRCUIT ENGINE OIL PRESSURE SWITCH (LOWER LEFT SIDE OF ENGINE, LEFT OF OIL FILTER) FROM SRS INDICATOR CIRCUIT (DIAGRAM 1 OF 2) FUEL GAUGE SENDING UNIT FUEL TANK UNIT GAUGE ASSEMBLY GRN WIRE GRN/ORG WIRE HIGH BEAM INDICATOR LIGHT IMMOBILIZER SYSTEM INDICATOR LIGHT LOW FUEL INDICATOR LIGHT M IND M/T MAINTENANCE REQUIRED INDICATOR LIGHT N IND OCCUPANT POSITION DETECTION SYSTEM (OPDS) UNIT (IN SEAT BACK) P IND PNK WIRE PNK/BLU WIRE R IND RED WIRE SEAT BELT REMINDER INDICATOR LIGHT SHIFT INDICATOR SRS UNIT (BELOW CENTER OF DASH, LEFT OF HEATER UNIT) TEST TACHOMETER CONNECTOR (LEFT SIDE OF ENGINE COMPT) UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) USA VEHICLE SPEED SENSOR (VSS) (TOP LEFT FRONT OF TRANSAXLE) WASHER FLUID LEVEL INDICATOR LIGHT WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRAIDED 24 25 BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRN/YEL WIRE DIMMING CIRCUIT FUSE 10 GAUGE ASSEMBLY GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IMMOBILIZER SYSTEM INDICATOR ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE SECONDARY HEATED SHIFT INDICATOR SHIFT LOCK DIODE TRANSMISSION RANGE SWITCH (ON TRANSAXLE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

A/C SYSTEM A/T A/T SHIFT SWITCH BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRAIDED 24 25 BRN WIRE BRN/WHT WIRE BRN/YEL WIRE DATA LINK CONNECTOR (DLC) (ON RIGHT SIDE OF FRONT CONSOLE) DOWN SHIFT SWITCH ECM/PCM (UNDER RIGHT SIDE OF DASH, BEHIND GLOVE BOX) EVAP BYPASS SOLENOID VALVE EVAP CANISTER VENT SHUT VALVE FUEL TANK PRESSURE SENSOR (UNDERSIDE OF VEHICLE, ON LEFT FRONT OF FUEL TANK) FUSE 17 GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT IN ON OR START ILU FTP ELD PSPSW IMMOBILIZER CONTROL UNIT- RECEIVER (ON STEERING COLUMN, NEAR LOCK CYLINDER) IMO FPR INH LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MPCS MRLY MULTIPLEX CONTROL UNIT ORG/ WIRE PARKING BRAKE SWITCH PNK WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE S-DN ATPD S-MODE S-UP ATPN ATPR ATPP SCS WEN MIL SEFMJ SEQUENTIAL SPORTSHIFT MODE SWITCH SLU+ TEST TACHOMETER CONNECTOR) UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UP SHIFT SWITCH VSV BKSW K-LINE SEFMJ VSSOUT NEP IMOCD WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
